#135259 - New '21 Big Tex 14GX-16 TANDEM AXLE GOOSENECK DUMP TRAILER

Jims Motors - Cuba, MO
https://jimsmotors.com/

Phone: 1-800-897-9840

Click to call from your smartphone!

Email: ml@jimsmotors.com

Address: Cuba, MO 65453

#135259

$10,995.00

BRAND NEW! 2021 BIG TEX 14GX-16 83" x 16' HEAVY DUTY TANDEM AXLE EXTRA WIDE GOOSENECK DUMP TRAILER. THIS UNIT WEIGHS 4,830#.
DESCRIPTION: The 14GX Tandem Axle Low Profile Extra Wide Dump Trailer from Big Tex Trailers is a great way to gain the features of our popular 14LX in a gooseneck configuration. This unit combines a tube frame and heavy duty cross members in addition to the most complete box unit in the industry.
SPECS: AXLE - 2 7,000# EZ Lube w/Elec. Brakes
JACK Dual - 12,000# Drop Leg - Side Wind
NECK - 10" I-Beam
TIRE - ST235/80 R-16 Load Range E
FLOOR - 10 Gauge Smooth Steel
WHEEL - 16" x 6" HD Black Mod 8 Bolt
FINISH - Superior Quality Finish is Applied for a Highly Decorative and Protective Finish.
LIGHTS - L.E.D. D.O.T. Stop, Tail, Turn & Clearance
COUPLER - 2-5/16" Adjustable Pin 25K
FENDERS - 9" x 72" 14 Ga. Diamond Plate Souble Square Broke
G.V.W.R. - 15,900#
ELEC. PLUG - 7-Way RV
HITCH TYPE - Gooseneck
MAIN FRAME - 8" I-Beam, 10#
SUSPENSION - Multi-Leaf Spring w/Equalizer
FINISH Prep - Steel is Cleaned to Ensure a Professional Smooth Finish.
SAFETY CHAINS - 3/8" Grd. 70 w/Safety Latch Hook 2 each
DUMP BODY SIDES - 24" Tall Sides 10 Gauge
DUMP BODY TOP RAIL - 3" x 2" Rectangular Tubing
G.A.W.R. Ea. Axle - 7,000#
DUMP BODY CROSSMEMBERS - 3" Channel, 16" Centers
THE 14GX ALSO COMES EQUIPPED WITH: Round Adjustable Pin 2-5/16" Gooseneck Coupler 25K Dual 12,000# Drop Leg Side Wind Lockable Pump & Battery Box Mounted Between Jacks 24" Tall, 12 Gauge Sides w/Formed Channel Supports 10 Gauge Steel Floor and Sides Fully Formed Tarp shroud on Front Crank Style Roll Tarp - Standard Equipped Tarp Rod Included to Secure Tarp on Rear J-Hooks on Sides & Rear for Tarp Control Stakepockets Along Sides Self Contained Electric/Hydraulic Scissor Hoist Power Up/Power Down Hydraulic Pump 12V Interstate Deep Cycle Battery 110V On-Board Battery Charger 5 Amp Dexter Brand Axles Cambered Axles w/EZ Lube Hubs Nev-R_Adjust Electric Brakes on All Hubs Grommet Mount Sealed Lighting L.E.D. Lighting Package Sealed, Modular Wiring Harness Complete Break-A-Way System
Zip Breakaway Cable Diamond Plate Fenders 2" square Tubing Top Rail on Dump Bed Combo Gate Barn Doors & Spreader Gate 4 1/2" D-Rings Inside Bed to Secure Equipment Spare Tire Mount Radial Tires.

WE OFFER FINANCING, WE ACCEPT TRADES AND WE DELIVER TOO!
WE'RE HAPPY TO ANSWER ANY QUESTIONS YA'LL MAY HAVE, SO DON'T HESITATE TO GIVE OUR SALES DEPARTMENT A CALL AT 1-800-897-9840.
